Product Overview
Technical Summary
| Product type | SIMOTICS S synchronous motor 1FT7 |
|---|---|
| Rated power | PN=0.85 kW |
| Rated speed | NN=3000 rpm |
| Torque | M0=3 Nm (100K) |
| Cooling | Naturally cooled |
| Frame size | IMB 5 (IM V1, IM V3) |
| Flange | Conventional flange (1FT6/1FK7 compatible) |
| Feedback | INCREM. ENCODER SIN/COS 1VSS 2048 S/R (ENCODER I-2048) |
| Temperature sensor | KTY temperature sensor |
| Shaft | Plain shaft |
| Protection | Degree of protection IP65 |
| Brake | Without holding brake |
Key Features
PN=0.85 kW, NN=3000 rpm and M0=3 Nm (100K).
INCREM. ENCODER SIN/COS 1VSS 2048 S/R (ENCODER I-2048) with KTY temperature sensor.
Frame size IMB 5 (IM V1, IM V3), conventional flange and plain shaft.
Naturally cooled; degree of protection IP65.
POWER CONNECTOR ROTATABLE and ENCODER CONNECTOR ROTATABLE.
Without holding brake; product cancellation.
Frequently Asked Questions
What is the exact motor line item?
It is the Siemens SIMOTICS S synchronous motor 1FT7042-5AF71-1NG1.
What are the motor rating and speed?
PN=0.85 kW, NN=3000 rpm and M0=3 Nm (100K).
What feedback and connectors are included?
It has a SIN/COS 1VSS 2048 S/R incremental encoder, a KTY temperature sensor, a rotatable POWER CONNECTOR and a rotatable ENCODER CONNECTOR.
What mechanical configuration does it have?
It has frame size IMB 5 (IM V1, IM V3), a conventional flange, a plain shaft and no holding brake.
What quantity, destination, schedule and additional BOM lines should be quoted?
Submit the requested quantity, destination, schedule context and any additional BOM lines with this exact item.
