Product Overview
Technical Summary
| Product type | SINAMICS G120 Power Module PM230 |
|---|---|
| Order number | 6SL3210-1NE24-5UL0 |
| Supply | 380-480 V 3AC +10/-10%, 47-63 Hz |
| Low-overload rating | 22 kW at 110% 60 s, 100% 240 s |
| Ambient temperature | 0 to +40 °C (LO) |
| Protection | Unfiltered, IP20 |
| Configuration | Without Control Unit and operating unit |
| Firmware | V4.4 or higher |
| Released for | CU240B/E-2 and CU230P-2 |
| Safety | No safety |
Key Features
SINAMICS G120 Power Module PM230, unfiltered, with IP20 degree of protection.
380-480 V 3AC +10/-10%, 47-63 Hz.
22 kW at 110% for 60 s and 100% for 240 s.
0 to +40 °C (LO).
419 x 275 x 204 mm (H x W x D), without Control Unit and operating unit.
Firmware version V4.4 or higher; released for CU240B/E-2 and CU230P-2. No safety.
Frequently Asked Questions
What is the exact product identity?
It is the Siemens SINAMICS G120 Power Module PM230, order number 6SL3210-1NE24-5UL0.
What supply does this power module use?
Supply is 380-480 V 3AC +10/-10% at 47-63 Hz.
What is included in this configuration?
It is without a Control Unit and operating unit, and has no safety.
What information should be included for a project quotation?
Provide the requested quantity, destination, schedule context, and any additional BOM lines.
