Product Overview
Technical Summary
| Product type | SINAMICS G120 Power Module PM230 |
|---|---|
| Low overload power | 55 kW at 110% 60 s, 100% 240 s |
| Supply | 380-480 V 3AC +10/-10%, 47-63 Hz |
| Protection | IP20 |
| Ambient temperature | 0 to +40 °C (LO) |
| Configuration | Without Control Unit and operating unit |
| Released for | CU240B/E-2 and CU230P-2 |
| Firmware version | V4.4 or higher |
| Product lifecycle | Product cancellation |
Key Features
Low overload: 55 kW at 110% for 60 s and 100% for 240 s.
380-480 V 3AC +10/-10%, 47-63 Hz.
Degree of protection: IP20; ambient temperature: 0 to +40 °C (LO).
634 x 350 x 316 mm (H x W x D).
Without Control Unit and operating unit; released for CU240B/E-2 and CU230P-2.
Firmware version V4.4 or higher; PM230 supported, no safety.
Frequently Asked Questions
What is the exact product type and order number?
It is the SINAMICS G120 Power Module PM230, order number 6SL3210-1NE31-1UL0.
What low-overload rating does this Power Module have?
Low overload is 55 kW at 110% for 60 s and 100% for 240 s.
What is included in this configuration?
It is without a Control Unit and operating unit.
What details should accompany a quotation request for this line item?
Provide the requested quantity, destination, schedule context, and any additional BOM lines.
