Product Overview
Technical Summary
| Product type | SINAMICS G120 PM 240-2 push-through Power Module |
|---|---|
| Supply | 200-240 V 3AC +10/-20%, 47-63 Hz |
| High overload power | 15 kW at 200% for 3 s, 150% for 57 s and 100% for 240 s; ambient temperature -20 to +50 °C (HO) |
| Low overload power | 18.5 kW at 150% for 3 s, 110% for 57 s and 100% for 240 s; ambient temperature -20 to +40 °C (LO) |
| Protection | IP20 |
| Included function | Integrated braking chopper |
| Not included | Control Unit and operating unit |
| Firmware release | CU firmware version V4.7 SP6 |
| Lifecycle | Product cancellation |
Key Features
PM 240-2 push-through Power Module, unfiltered, with integrated braking chopper.
15 kW at 200% for 3 s, 150% for 57 s and 100% for 240 s; ambient temperature -20 to +50 °C (HO).
18.5 kW at 150% for 3 s, 110% for 57 s and 100% for 240 s; ambient temperature -20 to +40 °C (LO).
200-240 V 3AC +10/-20%, 47-63 Hz; degree of protection IP20.
Push-through dimensions: 517 x 275 x 237 mm (H x W x D), frame size FSD.
Without Control Unit and operating unit; released as of CU firmware version V4.7 SP6.
Frequently Asked Questions
What is the high overload rating of Siemens 6SL3211-1PC26-8UL0?
High overload power is 15 kW at 200% for 3 s, 150% for 57 s and 100% for 240 s, with ambient temperature -20 to +50 °C (HO).
What is included in this configuration?
It is a PM 240-2 push-through Power Module with an integrated braking chopper. It is without Control Unit and operating unit.
What supply does this Power Module use?
Supply is 200-240 V 3AC +10/-20% at 47-63 Hz.
