Product Overview
Technical Summary
| Power module | SINAMICS G120 PM240-2 |
|---|---|
| High overload rating | 45 kW at 200% 3 s, 150% 57 s, 100% 240 s |
| Low overload rating | 55 kW at 150% 3 s, 110% 57 s, 100% 240 s |
| Supply | 200-240 V 3AC +10/-20%, 47-63 Hz |
| Braking | Integrated braking chopper |
| Construction | Push-through, unfiltered |
| Ambient temperature, HO | -20 to +50 °C (HO) |
| Ambient temperature, LO | -20 to +40 °C (LO) |
| Degree of protection | IP20 |
| Excluded items | Without Control Unit and operating unit |
Key Features
High overload: 45 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s; low overload: 55 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s.
200-240 V 3AC +10/-20%, 47-63 Hz.
Integrated braking chopper; push-through and unfiltered.
High overload: -20 to +50 °C (HO); low overload: -20 to +40 °C (LO).
754x384x358 mm (HxWxD); degree of protection IP20.
Without Control Unit and operating unit; Product cancellation; released as of Control Unit firmware version V4.7 SP6.
Frequently Asked Questions
What is the exact product line item?
It is Siemens 6SL3211-1PC31-8UL0, a spare SINAMICS G120 PM240-2 Power Module PM240-2.
What are the high- and low-overload ratings?
High overload is 45 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s. Low overload is 55 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s.
What is included in this configuration?
It is without Control Unit and operating unit.
What supply and protection specifications should be retained in the quotation?
Supply is 200-240 V 3AC +10/-20% at 47-63 Hz, and the degree of protection is IP20.
