Product Overview
Technical Summary
| Product | 6SL3211-1PE31-1AL0 |
|---|---|
| Type | SINAMICS G120 PM 240-2 push-through power module |
| Supply | 380-480 V 3 AC +10/-20%, 47-63 Hz |
| High overload | 45 kW at 200% 3 s, 150% 57 s, 100% 240 s |
| High overload ambient temperature | -20 to +50 °C (HO) |
| Low overload | 55 kW at 150% 3 s, 110% 57 s, 100% 240 s |
| Low overload ambient temperature | -20 to +40 °C (LO) |
| Protection | IP20 |
| Exclusions | Without Control Unit and operating unit |
| Firmware release | Released as of CU firmware version V4.7 SP6 |
| Lifecycle | Product cancellation |
Key Features
SINAMICS G120 PM 240-2 push-through power module with integrated Class A filter and integrated braking chopper.
45 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s; ambient temperature -20 to +50 °C (HO).
55 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s; ambient temperature -20 to +40 °C (LO).
380-480 V 3 AC +10/-20%, 47-63 Hz; degree of protection IP20.
Without Control Unit and operating unit; released as of CU firmware version V4.7 SP6.
Frequently Asked Questions
What is the exact line item?
It is Siemens 6SL3211-1PE31-1AL0, a SINAMICS G120 PM 240-2 push-through power module.
What overload ratings are specified?
High overload is 45 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s at -20 to +50 °C (HO). Low overload is 55 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s at -20 to +40 °C (LO).
What is included in this configuration?
It is without Control Unit and operating unit. The module has an integrated Class A filter and integrated braking chopper.
