Product Overview
Technical Summary
| Exact order number | 6SL3211-1PE32-5UL0 |
|---|---|
| Product type | SINAMICS G120 Power Module PM 240-2 |
| High-overload power | 110 kW at 200% 3 s, 150% 57 s, 100% 240 s |
| High-overload ambient temperature | -20 to +50 °C (HO) |
| Low-overload power | 132 kW at 150% 3 s, 110 kW 57 s, 100% 240 s |
| Low-overload ambient temperature | -20 to +40 °C (LO) |
| Supply | 380-480 V 3 AC +10/-20%, 47-63 Hz |
| Degree of protection | IP20 |
| Configuration exclusions | Without Control Unit and operating unit |
| Firmware release | CU firmware version V4.7 SP6 |
| Product lifecycle | Product cancellation |
Key Features
SINAMICS G120 Power Module PM 240-2, push-through and unfiltered, with an integrated braking chopper.
110 kW at 200% for 3 s, 150% for 57 s and 100% for 240 s; ambient temperature -20 to +50 °C (HO).
132 kW at 150% for 3 s, 110 kW for 57 s and 100% for 240 s; ambient temperature -20 to +40 °C (LO).
380-480 V 3 AC +10/-20%, 47-63 Hz; degree of protection IP20.
Dimensions are 754x384x358 (HxWxD). The unit is without Control Unit and operating unit.
Product cancellation; released as of CU firmware version V4.7 SP6.
Frequently Asked Questions
What is the exact Siemens line item?
It is Siemens 6SL3211-1PE32-5UL0, a SINAMICS G120 Power Module PM 240-2.
What high-overload performance does this power module provide?
It provides 110 kW at 200% for 3 s, 150% for 57 s and 100% for 240 s, with ambient temperature -20 to +50 °C (HO).
What is included in the configuration?
It is without Control Unit and operating unit.
What project details should accompany a quotation request?
Provide the requested quantity, destination, schedule context and any additional BOM lines.
