Product Overview
Technical Summary
| Product type | SINAMICS G120 PM250 power module |
|---|---|
| High-overload rated power | 30.00 kW | 40.00 hp |
| Light-overload rated power | 37.00 kW | 50.00 hp |
| Input | 3 AC, 380 … 480 V ±10 %, 47 … 63 Hz |
| Output frequency | 0 … 200 Hz vector control; 0 … 550 Hz V/f control |
| Maximum output current | 120.00 A |
| Connections | M6 bolt; 10.00 … 50.00 mm2 (AWG 8 … AWG 1) |
| Protection | IP20 / UL open type |
| Configuration | Without filter; possibility of regeneration; without control unit and BOP |
Key Features
Rated power (HO): 30.00 kW | 40.00 hp; rated current (HO): 60.00 A.
Rated power (LO): 37.00 kW | 50.00 hp; rated current (LO): 75.00 A.
3 AC input, line voltage 380 … 480 V ±10 %, and line frequency 47 … 63 Hz.
Output frequency: 0 … 200 Hz for vector control and 0 … 550 Hz for V/f control.
M6 bolt connections with 10.00 … 50.00 mm2 (AWG 8 … AWG 1) conductor cross-section; maximum motor cable length is 50 m (164.04 ft) shielded or 100 m (328.08 ft) unshielded.
PM250 without filter, possibility of regeneration, frame size FSE, IP20 / UL open type; without control unit and BOP.
Frequently Asked Questions
What is the exact product line item?
It is Siemens 6SL3225-0BE33-0UA0, a SINAMICS G120 PM250 power module.
What is the high-overload rating?
High-overload rated power is 30.00 kW | 40.00 hp, with rated current of 60.00 A.
What input supply does it use?
The input is 3 AC, 380 … 480 V ±10 %, at 47 … 63 Hz.
What is included in this configuration?
It is without a filter, without a control unit, and without BOP; it has the possibility of regeneration.
What information should be included for a quotation request?
Include the requested quantity, destination, schedule context, and any additional BOM line items.
