Product Overview
Technical Summary
| Input | 600 V DC |
|---|---|
| Output | 400 V 3 AC |
| Rated current | 85 A |
| Type of construction | booksize |
| Cooling | external air cooling |
| Pulse patterns | optimized |
| Safety functions | support of the extended Safety Integrated functions |
| Included cable | DRIVE-CLiQ cable |
| Lifecycle | Product cancellation |
Key Features
Input: 600 V DC; output: 400 V 3 AC; rated current: 85 A.
Type of construction: booksize.
External air cooling.
Optimized pulse patterns and support of the extended Safety Integrated functions.
DRIVE-CLiQ cable included.
Product cancellation.
Frequently Asked Questions
What are the electrical ratings of 6SL3121-1TE28-5AA3?
Input: 600 V DC; output: 400 V 3 AC; rated current: 85 A.
What is the construction and cooling of this Single Motor Module?
It has a booksize type of construction and external air cooling.
What configuration details should be retained in a quotation request?
Retain the 6SL3121-1TE28-5AA3 order number, 600 V DC input, 400 V 3 AC output, 85 A rating, booksize construction and external air cooling.
What should be included with the project line item?
Include the requested quantity, destination, schedule context and any additional BOM lines.
