Product Overview
Technical Summary
| Product type | IFP2200 PRO |
|---|---|
| Display | TFT widescreen display, LED backlighting; 21.5 in; 22" |
| Image resolution | 1 920 x 1 080 |
| Touch screen | Projective-capacitive multi-touch screen |
| Rated supply | 24 V DC; PELV / SELV floating |
| Permissible supply range | 19.2 V to 28.8 V |
| Interfaces | DisplayPort V1.2; 2 USB 2.0 type A |
| Detachable distance | 100 m; HDBaseT protocol |
| Mounting | Pedestal mounting; VESA mounting with VESA adapter set |
| Protection | IP65 at the front and rear |
| Power loss | 24 W typ.; 31 W max. |
Key Features
TFT widescreen display with LED backlighting, 21.5 in; 22" diagonal and 1 920 x 1 080 image resolution.
Projective-capacitive multi-touch screen with integrated mouse cursor control and monitor keyboard.
24 V DC rated supply, PELV / SELV floating, with a permissible range of 19.2 V to 28.8 V.
DisplayPort V1.2 and 2 USB 2.0 type A interfaces; USB interfaces are located on the rear.
Pedestal mounting with stand mounting and VESA mounting using a VESA adapter set; IP65 at the front and rear.
Frequently Asked Questions
What is the exact product type of 6AV7863-4MA14-2AA0?
The product type is IFP2200 PRO, a 22" multi-touch display with 1 920 x 1 080 resolution.
Which interfaces does this display have?
It has DisplayPort V1.2 and 2 USB 2.0 type A interfaces, with USB on the rear.
Which mounting options are supported?
It supports pedestal mounting, stand mounting and VESA mounting with a VESA adapter set. Front mounting and support arm mounting are not supported.
