Product Overview
Technical Summary
| Product type | IPC347G |
|---|---|
| Design | Rack PC, 19", 4U |
| Processor | Intel Pentium G4400 |
| Main memory | 4 GB (pre-installed) |
| Hard disk | 1 TB HDD |
| Interfaces | 2 industrial Ethernet interfaces; 2 PROFINET interfaces |
| Serial interfaces | 2x COM ports (RS 232, RS 422, RS 485) and 2x COM pin header |
| Video interfaces | 1x DisplayPort, 1x VGA |
| Supply voltage | 100 – 240 V AC |
| Operating system | Windows 10 IoT Enterprise 2019 LTSC, 64 bit, MUI |
| Mounting | For horizontal and vertical mounting |
| IP degree of protection | IP20 |
Key Features
Intel Pentium G4400 processor, 1 TB HDD, and 4 GB pre-installed main memory.
2 industrial Ethernet interfaces, 2 PROFINET interfaces, 1x DisplayPort, 1x VGA, and 2x COM ports with RS 232, RS 422, and RS 485.
2x USB on the front, 4x USB on the rear side, 2x USB internal, and 2x COM pin header.
100 – 240 V AC supply voltage; rated line frequency values of 50 Hz and 60 Hz.
For horizontal and vertical mounting; IP20 degree of protection.
Frequently Asked Questions
What is the exact product type for 6AG4012-2AA10-0AX0?
The product type designation is IPC347G, a Rack PC with a 19", 4U design.
Which interfaces does this SIMATIC IPC347G have?
It has 2 industrial Ethernet interfaces, 2 PROFINET interfaces, 1x DisplayPort, 1x VGA, and serial interfaces with 2x COM ports (RS 232, RS 422, RS 485) and 2x COM pin header.
What supply voltage and mounting options are specified?
The supply voltage is 100 – 240 V AC. The Rack PC is for horizontal and vertical mounting.
What quantity, destination, and schedule should be included in a quotation request?
Please provide the requested quantity, destination, and schedule context for this exact line item.
