Product Overview
Applications
Measures analog N-conductor and differential current in a SENTRON expansion-module configuration.
Technical Summary
| Product designation | I(N), I(Diff) expansion module, analog N conductor measurement, differential current measurement, 2 analog inputs |
|---|---|
| Supply | Via PAC 3200 / PAC4200 |
| Analog inputs | 2 |
| Maximum insulation voltage | 500 V AC |
| Protection class | IP20 |
| Electrical connection | Screw terminal |
| Fastening method | Pluggable |
| Operating ambient temperature | -10 °C to 55 °C |
| Storage ambient temperature | -25 °C to 70 °C |
| Lifecycle | Active Product |
Key Features
Analog N-conductor and differential current measurement.
2 analog inputs.
Supply is via PAC 3200 / PAC4200.
Plug-in fastening with a screw terminal electrical connection.
Protection class IP20; combustibility class V 0 according to UL 94.
Frequently Asked Questions
What is Siemens 7KM9200-0AD00-0AA0?
It is a SENTRON I(N), I(Diff) expansion module for analog N-conductor and differential current measurement with 2 analog inputs.
How is the 7KM9200-0AD00-0AA0 installed and connected?
It has plug-in fastening and a screw terminal electrical connection.
What protection and temperature data apply to this module?
Protection class is IP20. The operating ambient temperature is -10 °C to 55 °C, and the storage ambient temperature is -25 °C to 70 °C.
Is the 7KM9200-0AD00-0AA0 suitable for a reactive power meter?
No.
