Product Overview
Applications
I/O module removal and insertion
Used for holding an 80 mm wide I/O module for removal and insertion function.
Technical Summary
| Product type | SIMATIC DP bus module for ET 200M |
|---|---|
| Removal and insertion | Removal and insertion function |
| Lifecycle | Product cancellation |
Key Features
Product type
SIMATIC DP bus module for ET 200M.
I/O module width
Holds an 80 mm wide I/O module; width is 80 mm when installed.
Removal and insertion
Supports removal and insertion function for the held I/O module.
Dimensions
97 mm wide, 92 mm high, and 30 mm deep.
Weight
Weight, approx. 127 g.
Lifecycle
Product cancellation.
Frequently Asked Questions
What is Siemens 6ES7195-7HC00-0XA0?
It is a SIMATIC DP bus module for ET 200M that holds an 80 mm wide I/O module.
What module width does this bus module hold?
It holds an 80 mm wide I/O module; the width is 80 mm when installed.
What are its dimensions and weight?
The dimensions are 97 mm × 92 mm × 30 mm, and the approximate weight is 127 g.
Is this line item a current product?
It has the lifecycle status Product cancellation.
