Product Overview
Technical Summary
| Product type | SIMATIC S7-300 analog output spare part |
|---|---|
| Analog outputs | 4; Isochronous mode |
| Resolution | Max. 16 bit with overrange, including sign |
| Rated supply | 24 V DC |
| Voltage output ranges | 0 to 10 V; 1 V to 5 V; -10 V to +10 V |
| Current output ranges | 0 to 20 mA; -20 mA to +20 mA; 4 mA to 20 mA |
| Connection | 20-pin front connector |
Key Features
4 analog outputs; Isochronous mode.
Resolution with overrange, including sign: max. 16 bit.
Voltage: 0 to 10 V, 1 V to 5 V, and -10 V to +10 V; current: 0 to 20 mA, -20 mA to +20 mA, and 4 mA to 20 mA.
Potential separation is provided between the channels, between the channels and backplane bus, and between the channels and the electronics power supply.
Required front connector: 20-pin.
Frequently Asked Questions
What is the exact product line item?
It is Siemens SIMATIC S7-300 analog output spare part 6ES7332-7ND02-0AB0.
How many analog outputs does it have?
It has 4 analog outputs with Isochronous mode.
Which output ranges are supported?
Voltage ranges are 0 to 10 V, 1 V to 5 V, and -10 V to +10 V. Current ranges are 0 to 20 mA, -20 mA to +20 mA, and 4 mA to 20 mA.
What should accompany a quotation request for this line item?
Provide the requested quantity, destination, schedule context, and any additional BOM lines.
