Product Overview
Applications
Controls temperature through 4 closed-loop controllers.
Technical Summary
| Product type | SIMATIC S7-300 temperature control unit FM 355-2 C |
|---|---|
| Channels | 4 |
| Digital inputs | 8 |
| Analog inputs | 4 |
| Analog outputs | 4 |
| Rated load voltage L+ | 24 V DC |
| Permissible load voltage range | 20.4 V to 28.8 V DC |
| Output ranges | 0 to 10 V; -10 V to +10 V; 0 to 20 mA; 4 mA to 20 mA |
| Required front connector | 2x 20-pin |
| Product lifecycle | Product cancellation |
Key Features
4 analog inputs, 8 digital inputs and 4 analog outputs.
Rated load voltage L+: 24 V DC; permissible range: 20.4 V to 28.8 V DC.
Supports voltage, current, thermocouple and resistance thermometer inputs, including Pt 100.
4 closed-loop controllers; parameterizable characteristic linearization is available.
Includes a multi-language configuration package, manual and Getting Started in German, English and Italian on CD-ROM.
Frequently Asked Questions
What exact product is 6ES7355-2CH00-0AE0?
It is a Siemens SIMATIC S7-300 temperature control unit FM 355-2 C with 4 channels.
What I/O does this temperature control unit provide?
It has 4 analog inputs, 8 digital inputs and 4 analog outputs.
What supply voltage does it require?
The rated load voltage L+ is 24 V DC, with a permissible range of 20.4 V to 28.8 V DC.
What front connector is required?
The required front connector is 2x 20-pin.
What project details should accompany a quotation request?
Please provide the requested quantity, destination, schedule context and any additional BOM lines.
