Product Overview
Applications
The source identifies the unit as a temperature control unit with 4 channels and 4 closed-loop controllers.
Technical Summary
| Order number | 6ES7355-2SH00-0AE0 |
|---|---|
| Product type | SIMATIC S7-300 FM 355-2S temperature control unit |
| Channels | 4 |
| Digital inputs | 8 |
| Digital outputs | 8 |
| Analog inputs | 4 |
| Load voltage L+ | 24 V DC rated value; 20.4 V to 28.8 V permissible range |
Key Features
FM 355-2S temperature control unit with 4 channels and 4 closed-loop controllers.
8 digital inputs and 8 digital outputs; the outputs have electronic short-circuit protection.
Supports voltage, current, thermocouple and resistance thermometer input ranges, including 0 to +10 V, 0 to 20 mA, Type B/E/J/K/R/S and Pt 100.
Load voltage L+ rated value: 24 V DC; permissible range: 20.4 V to 28.8 V.
Includes a multi-language configuration package, manual and Getting Started in de, en and it on CD-ROM.
Required front connector: 2x 20-pin.
Frequently Asked Questions
What is the exact product variant?
The exact line item is Siemens 6ES7355-2SH00-0AE0, SIMATIC S7-300 FM 355-2S temperature control unit.
How many channels and I/O points does it have?
It has 4 channels, 4 analog inputs, 8 digital inputs and 8 digital outputs.
What supply voltage does it use?
Load voltage L+ is 24 V DC, with a permissible range of 20.4 V to 28.8 V.
Which front connector is required?
The required front connector is 2x 20-pin.
What should be included in a project quotation request?
Include the exact order number, requested quantity, destination, schedule context and any additional BOM lines.
