Product Overview
Technical Summary
| Product type | DIQ 16x24VDC/0.5A |
|---|---|
| Digital inputs | 16; parameterizable as DIQ |
| Digital outputs | 16; parameterizable as DIQ |
| Rated load voltage | 24 V DC |
| Output current, rated | 0.5 A per signal 1 |
| Connections | 8xM12 |
| Degree of protection | IP65/67 |
| Firmware version | V2.0.x |
| Product lifecycle | Active Product |
Key Features
16 digital inputs and 16 digital outputs, parameterizable as DIQ.
Rated load voltage: 24 V DC; permissible range: 20.4 V to 28.8 V.
Current-sourcing outputs with 0.5 A rated output current per signal 1 and electronic short-circuit protection per channel.
8 encoder supply outputs; total output current is 1.4 A, with a maximum of 0.7 A per load voltage.
8xM12 connections and IP65/67 degree of protection.
Configurable with STEP 7 V14 or higher and supports I&M0 to I&M3, diagnostic alarms, and channel status display.
Frequently Asked Questions
What is the exact product type of Siemens 6ES7143-5AH00-0BA0?
The product type is DIQ 16x24VDC/0.5A.
How many digital inputs and outputs does this module have?
It has 16 digital inputs and 16 digital outputs, both parameterizable as DIQ.
What load voltage does the module use?
The rated load voltage is 24 V DC, with a permissible range of 20.4 V to 28.8 V.
What connections and protection does the configuration have?
It has 8xM12 connections and IP65/67 degree of protection.
What project details should be supplied for a quotation?
Provide the requested quantity, destination, schedule, and any additional BOM lines.
