Product Overview
Applications
Supports Motion Control technology objects, with 800 available Motion Control resources.
Supports PID_Compact, PID_3Step and PID-Temp controllers with integrated optimization.
Supports OPC UA Client and OPC UA Server; a "Small" runtime license is required.
Technical Summary
| Exact order number | 6ES7513-1AL02-0AB0 |
|---|---|
| CPU type | CPU 1513-1 PN |
| Program work memory | 300 KB |
| Data work memory | 1.5 MB |
| PROFINET interfaces | 1; PROFINET IRT with 2-port switch |
| RJ 45 Ethernet ports | 2 |
| Processing time for bit operations | 40 ns, typ. |
| Rated supply voltage | 24 V DC |
| Permissible supply voltage | 19.2 V to 28.8 V DC |
| SIMATIC Memory Card | Required; 1 slot |
Key Features
300 KB for program and 1.5 MB for data.
1st interface: PROFINET IRT with 2-port switch; 2 ports and RJ 45 (Ethernet).
40 ns typical processing time for bit operations.
Rated value (DC): 24 V; permissible range: 19.2 V to 28.8 V.
1 SIMATIC Memory Card slot; SIMATIC Memory Card required.
Product cancellation.
Frequently Asked Questions
What exact CPU is this line item?
It is the Siemens 6ES7513-1AL02-0AB0, CPU 1513-1 PN.
What memory does the CPU provide?
It has 300 KB of work memory for the program and 1.5 MB for data.
Which network interface is included?
The 1st interface is PROFINET IRT with a 2-port switch and 2 RJ 45 (Ethernet) ports.
Is a SIMATIC Memory Card included in the configuration?
It is without a SIMATIC Memory Card; a SIMATIC Memory Card is required.
What project details should be included with a quotation request?
Provide the requested quantity, destination, schedule context and any additional BOM lines.
