Product Overview
Technical Summary
| Product type | CPU 412-5H PN/DP |
|---|---|
| Firmware version | V6.0 |
| Integrated work memory | 1 Mbyte (512 kbyte program, 512 kbyte data) |
| PROFINET IO Controller | 1 |
| PROFIBUS DP masters | 2 integrated |
| MPI transmission rate, max. | 12 Mbit/s |
| PROFINET transmission rate, max. | 100 Mbit/s |
Key Features
Central processing unit for S7-400H and S7-400F/FH with HW functional status 1 and firmware version V6.0.
1 Mbyte integrated work memory: 512 kbyte for program and 512 kbyte for data; not expandable.
1 MPI/DP interface, 1 DP interface, 1 PROFINET interface, and 2 interfaces for synchronization modules. PROFINET IO Controller and PROFIBUS DP master are supported.
Frequently Asked Questions
What is the exact product type of Siemens 6ES7412-5HK06-0AB0?
It has the product type designation CPU 412-5H PN/DP.
What memory is integrated in this CPU?
It has 1 Mbyte integrated work memory: 512 kbyte for the program and 512 kbyte for data. The work memory is not expandable.
Which interfaces are provided?
It has 1 MPI/DP interface, 1 DP interface, 1 PROFINET interface, and 2 interfaces for synchronization modules.
What information should be included when requesting this line item?
Include the exact order number 6ES7412-5HK06-0AB0, requested quantity, destination, schedule context, and any additional BOM lines.
