Product Overview
Applications
Supports PROFINET IO Controller and PROFINET IO Device functions.
Supports PROFIBUS DP master and PROFIBUS DP device functions via a CM DP module.
Supports Motion Control technology objects, including speed-controlled, positioning and synchronous axes.
Technical Summary
| Product type | CPU 1510SP-1 PN |
|---|---|
| Function | Central processing unit for ET 200SP |
| Program work memory | 200 KB |
| Data work memory | 1 MB |
| PROFINET interface | 1; PROFINET IRT with integrated 3-port switch |
| PROFINET IO Devices, max. | 128 |
| Supply voltage | 24 V DC; permissible range 19.2 V to 28.8 V DC |
| SIMATIC Memory Card | Required; 1 slot; plug-in load memory, max. 32 Gbyte |
| Firmware version | V4.0; firmware update possible |
Key Features
CPU 1510SP-1 PN for ET 200SP with 200 KB integrated work memory for the program and 1 MB for data.
One PROFINET interface with PROFINET IRT, an integrated 3-port switch and 6 ns bit performance.
A SIMATIC Memory Card and BusAdapter are required; the supplied server module is 6ES7193-6PA00-0AA0.
Up to 128 connectable PROFINET IO Devices and up to 64 IO Devices with IRT.
Rated supply voltage: 24 V DC; permissible range: 19.2 V to 28.8 V DC.
Firmware version V4.0; firmware update possible. Configurable with STEP 7 TIA Portal V20 with FW V4.0 or V18 with FW V3.0 and higher.
Frequently Asked Questions
What exact Siemens line item is this CPU?
It is Siemens 6ES7510-1DK03-0AB0, product type CPU 1510SP-1 PN for ET 200SP.
Which memory and interface configuration does it have?
It has 200 KB program work memory, 1 MB data work memory and one PROFINET IRT interface with an integrated 3-port switch.
What must be included in the configuration?
A SIMATIC Memory Card and BusAdapter are required. The server module 6ES7193-6PA00-0AA0 is included.
What should I provide for a project quotation?
Provide the requested quantity, destination, schedule context and any additional BOM lines.
