Product Overview
Technical Summary
| Product type | CPU 1510SP F-1 PN |
|---|---|
| Firmware version | V4.0 |
| Program work memory | 300 kbyte |
| Data work memory | 1 Mbyte |
| Rated supply voltage | 24 V DC |
| PROFINET interfaces | 1 |
| PROFIBUS interfaces | 1; Via CM DP module |
| PROFINET IO Controller | Yes |
| Maximum connectable IO Devices | 128; In total, up to 512 distributed I/O devices can be connected via AS-i, PROFIBUS or PROFINET |
Key Features
CPU 1510SP F-1 PN central processing unit for ET 200SP.
300 kbyte integrated work memory for the program and 1 Mbyte for data.
1st interface: PROFINET IRT with a 3-port switch and 6 ns bit performance.
Includes server module 6ES7193-6PA00-0AA0.
SIMATIC Memory Card required; BusAdapter required for port 1 and 2.
Frequently Asked Questions
What is the exact product type of Siemens 6ES7510-1SK03-0AB0?
The product type is CPU 1510SP F-1 PN, a SIMATIC DP central processing unit for ET 200SP.
What memory is available on the CPU 1510SP F-1 PN?
It has 300 kbyte integrated work memory for the program and 1 Mbyte for data. A SIMATIC Memory Card is required; plug-in load memory is supported up to 32 Gbyte.
Which interfaces are provided?
It has 1 PROFINET interface with PROFINET IRT and a 3-port switch, plus 1 PROFIBUS interface via a CM DP module. A BusAdapter is required for port 1 and 2.
What is included in this configuration?
The configuration includes server module 6ES7193-6PA00-0AA0. The SIMATIC Memory Card and required BusAdapter are not included in the stated configuration.
What should I provide for a project quotation?
Provide the requested quantity, destination, schedule context, and any additional BOM lines for quotation review.
