Product Overview
Applications
Supports Motion Control technology objects, including speed-controlled, positioning and synchronous axes.
Supports OPC UA Client and OPC UA Server functions for data access, method calls, alarms and conditions.
Supports PROFINET IO Controller and PROFINET IO Device communication.
Technical Summary
| Product type | CPU 1512SP-1 PN |
|---|---|
| Firmware version | V4.0 |
| Program work memory | 400 kbyte |
| Data work memory | 2 Mbyte |
| Supply voltage | 24 V DC rated; 19.2 V to 28.8 V permissible |
| PROFINET interfaces | 1 |
| PROFINET ports | 3; 1 integrated + 2 via BusAdapter |
| PROFINET Security Class | 1 |
| Required items | SIMATIC Memory Card and BusAdapter required |
Key Features
CPU 1512SP-1 PN for ET 200SP with 6 ns bit-operation processing time.
400 kbyte integrated work memory for the program and 2 Mbyte for data.
1 PROFINET interface with IRT, an integrated switch, and 3 ports: 1 integrated plus 2 via BusAdapter.
Rated DC supply voltage: 24 V; permissible range: 19.2 V to 28.8 V.
Includes server module 6ES7193-6PA00-0AA0. SIMATIC Memory Card and BusAdapter are required; they are not included in this line item.
Frequently Asked Questions
What exact CPU is represented by order number 6ES7512-1DM03-0AB0?
It is the SIMATIC DP CPU 1512SP-1 PN for ET 200SP.
What memory does the CPU have?
It has 400 kbyte integrated work memory for the program and 2 Mbyte for data.
What supply voltage is required?
The rated DC supply voltage is 24 V, with a permissible range of 19.2 V to 28.8 V.
Which items are required but not included?
It requires a SIMATIC Memory Card and BusAdapter. They are not included; the server module 6ES7193-6PA00-0AA0 is included.
