Product Overview
Applications
Supports Motion Control technology objects with 1 120 available Motion Control resources.
Technical Summary
| Product type | CPU 1512SP F-1 PN |
|---|---|
| Program work memory | 600 kbyte |
| Data work memory | 2 Mbyte |
| PROFINET interface | 1 PROFINET IRT interface with integrated 3-port switch |
| Rated DC supply voltage | 24 V |
| Permissible DC supply voltage | 19.2 V to 28.8 V |
| PROFINET IO Controllers | 1 integrated |
| Maximum connectable IO Devices | 128 |
Key Features
CPU 1512SP F-1 PN for ET 200SP with FS04 hardware functional status and firmware version V4.0.
Integrated work memory: 600 kbyte for the program and 2 Mbyte for data.
One PROFINET IRT interface with an integrated 3-port switch and 6 ns bit performance.
Includes server module 6ES7193-6PA00-0AA0. A SIMATIC Memory Card is required; a BusAdapter is required for port 1 and port 2.
Rated DC supply voltage: 24 V; permissible range: 19.2 V to 28.8 V.
Frequently Asked Questions
What is the exact product type of Siemens 6ES7512-1SM03-0AB0?
The product type is CPU 1512SP F-1 PN, a SIMATIC DP central processing unit for ET 200SP.
What memory does this CPU provide?
It has 600 kbyte of integrated work memory for the program and 2 Mbyte for data.
What interface and port requirements apply?
It has 1 PROFINET IRT interface with an integrated 3-port switch. A BusAdapter is required for port 1 and port 2.
Is a SIMATIC Memory Card included?
It is not included in the stated configuration; a SIMATIC Memory Card is required.
