Product Overview
Technical Summary
| Product type | CPU 1514SP F-2 PN |
|---|---|
| Firmware version | V4.0 |
| Program work memory | 900 kbyte |
| Data work memory | 3.5 Mbyte |
| Bit operation processing time | 6 ns, typical |
| PROFINET interfaces | 2 |
| Rated DC supply voltage | 24 V |
| Included server module | 6ES7193-6PA00-0AA0 |
Key Features
CPU 1514SP F-2 PN central processing unit with SIMATIC DP designation for ET 200SP.
Integrated work memory: 900 kbyte for the program and 3.5 Mbyte for data.
1st interface: PROFINET IRT with 2-port switch; 2nd interface: PROFINET RT.
Bit operations have a typical processing time of 6 ns.
Rated DC supply voltage: 24 V; permissible range: 19.2 V to 28.8 V.
SIMATIC Memory Card required; BusAdapter required for the 1st interface. Server module 6ES7193-6PA00-0AA0 is included.
Frequently Asked Questions
What is the exact product type of Siemens 6ES7514-2SN03-0AB0?
It is a SIMATIC DP CPU 1514SP F-2 PN central processing unit for ET 200SP.
What memory does this CPU provide?
It has 900 kbyte of integrated work memory for the program and 3.5 Mbyte for data.
Which interfaces are provided?
The 1st interface is PROFINET IRT with a 2-port switch, and the 2nd interface is PROFINET RT.
What must be retained in the configuration request?
A SIMATIC Memory Card is required, and a BusAdapter is required for the 1st interface.
