Product Overview
Applications
The installed S7-1500 Failsafe Software Controller CPU 1505SP F provides fail-safe software control.
The installed WinCC Runtime Advanced V17 provides visualization.
The controller supports PROFINET IO Controller, PROFINET IO Device, PROFIBUS DP master and PROFIBUS DP device communication.
Motion Control technology objects are supported, with 2 400 available Motion Control resources.
Technical Summary
| Product type | CPU 1515SP PC2 F |
|---|---|
| Firmware version | V21.9 |
| Supply voltage | 24 V DC; permissible range: 19.2 V to 28.8 V DC |
| Main memory | 8 GB RAM |
| CFast memory card | 128 GB flash memory |
| PROFINET interfaces | 1 |
| PROFIBUS interfaces | 1 |
| Industrial Ethernet interfaces | 2 |
| USB interfaces | 4; 2x USB 2.0, 2x USB 3.0 |
Key Features
CPU 1515SP PC2 F with HMI 128PT; the basic device is 6ES7677-2DB40-0AA0.
S7-1500 Failsafe Software Controller CPU 1505SP F V2x and WinCC Runtime Advanced V17 are preinstalled, with a 128 PowerTags license.
8 GB RAM and a 128 GB CFast flash memory card are supplied; a SIMATIC memory card is not required.
Interfaces include 1 PROFINET connection for an ET 200SP BusAdapter, 1x 10/100/1000 Mbps Ethernet, 2x USB 3.0, 2x USB 2.0 and 1x DisplayPort.
Rated supply is 24 V DC, with a permissible range from 19.2 V to 28.8 V DC and reverse polarity protection.
The PROFINET interface supports up to 128 connectable IO Devices, including up to 64 IO Devices with IRT.
Frequently Asked Questions
What exact configuration does Siemens 6ES7677-2SB42-0GK0 have?
It has CPU 1515SP PC2 F, HMI 128PT, 8 GB RAM, 128 GB CFast storage, and the basic device 6ES7677-2DB40-0AA0.
Which software is preinstalled?
S7-1500 Failsafe Software Controller CPU 1505SP F V2x and WinCC Runtime Advanced V17 are preinstalled, with a 128 PowerTags license.
What supply voltage does it use?
The rated supply is 24 V DC. The permissible range is from 19.2 V to 28.8 V DC, with reverse polarity protection.
Which interfaces are available?
It has 1 PROFINET connection for an ET 200SP BusAdapter, 1x 10/100/1000 Mbps Ethernet, 2x USB 3.0, 2x USB 2.0 and 1x DisplayPort.
What should be included in a quotation request?
Include the requested quantity, destination, schedule context and any additional BOM lines.
