Product Overview
Technical Summary
| Product type | MP377 12" touch |
|---|---|
| Display | 12.1 in TFT color display, 65 536 colors |
| Resolution | 800 pixel x 600 pixel |
| Touch screen | Analog, resistive |
| User data memory | 12 288 kbyte |
| Interfaces | 1x RS 422, 1x RS 485, 2x Ethernet (RJ45), 2x USB |
| Memory card slots | 1x CF card slot; 1x Multimedia Card slot, up to 128 MB |
| Protocols | PROFINET IO, PROFIBUS, EtherNet/IP, MPI, TCP/IP, Sm@rtServer, MODBUS |
| Supply voltage | DC |
| Rated current consumption | 1.5 A |
| Protection | IP65 front; IP20 rear; NEMA 4, NEMA 12 front when installed |
| Product lifecycle | Announcement of product phase-out; new part blocked for delivery as of 01.01.2015 |
Key Features
MP377 12" touch; customer-specific configuration: No.
TFT color display with 12.1 in screen diagonal, 65 536 colors and 800 pixel x 600 pixel resolution. Analog, resistive touch screen.
12 288 kbyte available for user data; Flash / RAM memory.
1x RS 422, 1x RS 485, 2x Ethernet (RJ45), 2 USB interfaces, 1x CF card slot and 1x Multimedia Card slot up to 128 MB. USB interfaces support up to 1 GB respectively.
PROFINET IO, PROFIBUS, EtherNet/IP, MPI, TCP/IP, Sm@rtServer and MODBUS: Yes. PROFIsafe and software interfaces: No.
DC supply voltage, 1.5 A rated current consumption and 36 W typical active power input. Maximum permissible angle of inclination without external ventilation: 35°.
Frequently Asked Questions
What is the exact product variant?
It is Siemens 6AV6644-0AA01-2AX0, MP377 12" touch, with no customer-specific configuration.
Which interfaces and protocols does this line item have?
It has 1x RS 422, 1x RS 485, 2x Ethernet (RJ45), 2 USB interfaces, PROFINET IO, PROFIBUS, EtherNet/IP, MPI, TCP/IP, Sm@rtServer and MODBUS. PROFIsafe is not available.
What display and memory configuration should be retained in the quotation?
The display is a 12.1 in TFT color display with 65 536 colors and 800 pixel x 600 pixel resolution. User data memory is 12 288 kbyte.
Can the new part be purchased?
The new part has been blocked for delivery as of 01.01.2015. The spare part can continue to be purchased as required, but its price may deviate from the new part.
