Product Overview
Technical Summary
| Product type | ITC1500 V3 industrial thin client |
|---|---|
| Display | 15.6 in TFT widescreen display, LED backlighting |
| Touch screen | Projective-capacitive multi-touch screen |
| Resolution | 1 366 x 768 |
| Industrial Ethernet | 2 ports, switch; up to 1 000 Mbit/s |
| USB interfaces | 4, on rear |
| Supply | 24 V DC; permissible range 19.2 V to 28.8 V |
| Active power input, typ. | 34 W |
| Mounting | Built-in unit; front mounting |
| Protection | IP65 at the front; IP20 at the rear |
| Product lifecycle | Product cancellation |
Key Features
15.6 in TFT widescreen display with LED backlighting, 1 366 x 768 resolution and projective-capacitive multi-touch screen.
2 industrial Ethernet interfaces with switch function and transmission rate up to 1 000 Mbit/s.
Sm@rtServer, RDP and VNC viewer are supported; Citrix and SINUMERIK are not supported.
24 V DC rated supply value, permissible range 19.2 V to 28.8 V, and typical active power input of 34 W.
Built-in unit for front mounting; support arm and stand mounting are not supported. Protection is IP65 at the front and IP20 at the rear.
Product cancellation; the collected description identifies it as a spare part and built-in unit.
Frequently Asked Questions
What display and touch configuration does 6AV6646-1BA15-0NA0 have?
It has a 15.6 in TFT widescreen display with 1 366 x 768 resolution and a projective-capacitive multi-touch screen.
Which interfaces are available on this configuration?
It has 2 industrial Ethernet ports with switch function and 4 USB interfaces on the rear.
What supply voltage is required?
The rated supply is 24 V DC, with a permissible range from 19.2 V to 28.8 V.
How should this line item be included in a project quotation?
Provide the requested quantity, destination, schedule context and any additional BOM lines with the exact line item.
