Product Overview
Technical Summary
| Product type | ITC2200 V3 |
|---|---|
| Display | TFT widescreen display, LED backlighting; 21.5 in; 22" |
| Image resolution | 1 920 x 1 080 |
| Touch operation | Projective-capacitive multi-touch screen |
| Supply voltage | 24 V DC; permissible range from 19.2 V to 28.8 V |
| Industrial Ethernet | 2 ports (switch); transmission rate up to 1 000 Mbit/s |
| USB interfaces | 4; on rear |
| Terminal link protocols | Sm@rtServer, RDP and VNC viewer |
| Mounting | Built-in unit; front mounting |
| Front protection | IP65 |
| Product lifecycle | Announcement of product phase-out |
Key Features
TFT widescreen display with LED backlighting, 21.5 in; 22", and 1 920 x 1 080 resolution.
Projective-capacitive multi-touch screen with monitor keyboard.
24 V DC rated supply with a permissible range from 19.2 V to 28.8 V.
2 industrial Ethernet ports in a switch, 4 USB interfaces, and support for TCP/IP, DHCP, SNMP, DCP and LLDP.
Built-in unit for front mounting; IP65 at the front.
Announcement of product phase-out.
Frequently Asked Questions
What exact product is 6AV6646-1BA22-1AA0?
It is the SIMATIC ITC2200 V3 industrial thin client, built-in unit.
What display and touch configuration does this line item have?
It has a TFT widescreen display with LED backlighting, 21.5 in; 22", 1 920 x 1 080 resolution, and a projective-capacitive multi-touch screen.
What supply voltage and interfaces should be retained in the BOM?
Retain 24 V DC supply, 2 industrial Ethernet ports in a switch, and 4 USB interfaces; the USB interfaces are on the rear.
How is this unit mounted and protected?
It is a built-in unit for front mounting and has IP65 protection at the front.
What should accompany a quotation request for this line item?
Provide the requested quantity, destination, schedule context, and any additional BOM lines.
