Product Overview
Technical Summary
| Product type | ITC1900 V3 PRO |
|---|---|
| Display | TFT widescreen display, LED backlighting |
| Screen diagonal | 18.5 in; 19" |
| Image resolution | 1 366 x 768 |
| Touch operation | Projective-capacitive multi-touch screen |
| Mounting | Support arm mounting; suitable for support arm without extension components |
| Supply | DC, rated value 24 V; permissible range 19.2 V to 28.8 V |
| Industrial Ethernet | 2 ports (switch); transmission rate, max. 1 000 Mbit/s |
| USB | 4 interfaces on rear |
| Protection | IP65 front and rear; NEMA 4x (when installed) at front |
Key Features
TFT widescreen LED display with 1 366 x 768 resolution, 16 777 216 colors and projective-capacitive multi-touch operation.
2 Industrial Ethernet ports in a switch configuration, 4 USB interfaces on the rear and USB keyboard/mouse connection.
Rated supply: 24 V; permissible DC range: 19.2 V to 28.8 V; typical active power input: 34 W.
Prepared for support arm without extension components; front, stand and built-in mounting are not provided. Maximum permitted tilt is 35° forward or backward from vertical.
Supports TCP/IP, DHCP, SNMP, DCP, LLDP, HTTP, HTTPS, HTML5, XML, CSS, JavaScript, Sm@rtServer, RDP, VNC viewer, Citrix and SINUMERIK.
IP65 at the front and rear. The front has NEMA 4x (when installed), Enclosure Type 4, Enclosure Type 4x and Enclosure Type 12 protection.
Frequently Asked Questions
What is the exact product type of 6AV6646-1BC18-0AA0?
It is the SIMATIC ITC1900 V3 PRO industrial thin client.
What display configuration does this line item have?
It has a TFT widescreen LED display with an 18.5 in; 19" screen diagonal, 1 366 x 768 resolution and projective-capacitive multi-touch.
Which interfaces are provided?
It has 2 Industrial Ethernet ports in a switch configuration and 4 USB interfaces on the rear, including USB keyboard/mouse connection.
How is the unit mounted?
It has support arm mounting and is suitable for a support arm without extension components. Front, stand and built-in mounting are not provided.
What project quotation details should be supplied for this line item?
Provide the requested quantity, destination, schedule context and any additional BOM lines for the quotation request.
