Product Overview
Technical Summary
| Product type | KP400 Comfort |
|---|---|
| Display | 4.3 in TFT widescreen, 480 pixel × 272 pixel |
| Function keys | 8, all with LEDs |
| Industrial Ethernet interfaces | 1 |
| RS 422 / 485 interfaces | 1 combined |
| USB interface | 1 USB 2.0; USB Mini B, 5-pole |
| Supply | 24 V DC; permissible range from 19.2 V to 28.8 V |
| Configuration memory | 4 Mbyte; Windows CE 6.0; WinCC Comfort V11 |
Key Features
4.3 in TFT widescreen display with 480 pixel × 272 pixel resolution, 16 777 216 colors and 8 function keys with LEDs.
1 industrial Ethernet interface, 1 combined RS 422 / 485 interface, 1 USB 2.0 interface and 2 SD card slots; supports PROFINET, PROFIBUS, EtherNet/IP and MPI.
DC supply with a rated value of 24 V, permissible range from 19.2 V to 28.8 V, and typical active power input of 3.1 W.
4 Mbyte memory available for user data, Windows CE 6.0 and configuration from WinCC Comfort V11.
Vertical mounting; landscape-format mounting is possible, with a maximum permissible angle of inclination of 35° without external ventilation.
IP65 at the front and IP20 at the rear; product lifecycle: Announcement of product phase-out.
Frequently Asked Questions
What is the exact product variant?
The exact product is Siemens 6AV2124-1DC01-0AX0, SIMATIC HMI KP400 Comfort.
Which display and key configuration does this line item have?
It has a 4.3 in TFT widescreen display with 480 pixel × 272 pixel resolution and 8 function keys with LEDs. Touch operation is not included.
Which communication interfaces and protocols are supported?
It has 1 industrial Ethernet interface, 1 combined RS 422 / 485 interface and 1 USB 2.0 interface. Supported protocols include PROFINET, PROFIBUS, EtherNet/IP and MPI.
What quantity, destination and schedule should be included in a quotation request?
Provide the requested quantity, destination and schedule, and indicate whether additional BOM lines should be included.
