Product Overview
Technical Summary
| Product type | SINAMICS G120 CU240E-2 DP-F control unit |
|---|---|
| Safety functions | STO; SS1, SLS, SSM and SDI |
| Communication | PROFIBUS DP |
| Standard digital inputs | 6 |
| Fail-safe digital inputs | 3 (Use of 6 × DI Standard) |
| Relay changer outputs | 2 |
| Analog / digital inputs | 2 (Differential input) |
| Analog outputs | 2 (Non-isolated output) |
| Power supply | DC 24 V via the Power Module; DC 20 … 29 V via an external power supply |
| Degree of protection | IP20 / UL open type |
| Configuration exclusion | Without Power Module |
Key Features
E-type Safety Integrated STO; F-type SS1, SLS, SSM and SDI.
PROFIBUS DP communication, USB interface and SD/MMC interface.
6 standard digital inputs, 3 fail-safe digital inputs using 6 × DI Standard, 2 relay changer outputs, 2 differential analog/digital inputs and 2 non-isolated analog outputs.
V/f linear / square-law / parameterizable, V/f with flux current control (FCC), V/f ECO linear / square-law, sensorless vector control and encoderless torque control.
DC 24 V via the Power Module or DC 20 … 29 V via an external power supply; IP20 / UL open type.
Dimensions: 73.0 mm W × 199.0 mm H × 46.0 mm D; net weight: 0.49 kg.
Frequently Asked Questions
What is the exact Siemens line item?
It is the Siemens 6SL3244-0BB13-1PA1 SINAMICS G120 CU240E-2 DP-F control unit.
Which communication and I/O does this configuration have?
It has PROFIBUS DP, 6 standard digital inputs, 3 fail-safe digital inputs using 6 × DI Standard, 2 relay changer outputs, 2 differential analog/digital inputs and 2 non-isolated analog outputs.
What power supply options are specified?
The supply is DC 24 V via the Power Module or DC 20 … 29 V via an external power supply.
Is the Power Module included in this configuration?
It is without a Power Module.
What quantity, destination, schedule and additional BOM lines should be included in the inquiry?
Include the requested quantity, destination, schedule context and any additional project BOM lines with this exact line item.
