Product Overview
Technical Summary
| Product type | Shield connection |
|---|---|
| Included components | 5 shield terminals, 5 shield supports, 5 support elements |
| Mounting | Can be plugged into ET 200SP BaseUnit |
| Ambient temperature during operation | -40 °C to 70 °C |
| Installation altitude above sea level, max. | 5 000 m |
| Dew point, min. | -60 °C; suitable for dry room applications |
| Material | Brass, nickel-plated |
| Product lifecycle | Active Product |
Key Features
Shield connection capacity
Set for 5 shield connections.
Included components
Has 5 shield terminals, 5 shield supports and 5 support elements.
Mounting
Can be plugged into an ET 200SP BaseUnit.
Dimensions and material
Dimensions: 15 mm width, 14 mm height and 80 mm depth. Material: brass, nickel-plated.
Frequently Asked Questions
What does the Siemens 6ES7193-6SC20-1AM0 include?
It includes 5 shield terminals, 5 shield supports and 5 support elements.
How is the shield connection set mounted?
It can be plugged into an ET 200SP BaseUnit.
What are its operating ambient temperature limits?
The ambient temperature during operation is -40 °C to 70 °C.
What information should accompany a quotation request for this line item?
Include the requested quantity, destination, schedule context and any additional BOM lines.
