Product Overview
Technical Summary
| Product type | MTP1200 Unified Comfort PRO |
|---|---|
| Display | 12.1 in widescreen TFT |
| Resolution | 1 280 × 800 pixel |
| Touch operation | Multi-touch screen |
| Mounting | Pedestal, vertical position |
| Supply voltage | 24 V DC; permissible range 19.2 V to 28.8 V |
| Industrial Ethernet | 2 interfaces; 2 switch ports + 1 independent port |
| USB interfaces | 4; USB 3.1 Gen. 1 (type A) |
| Protection | IP65 at the front and rear |
| Product lifecycle | Active Product |
Key Features
TFT display with 16 777 216 colors and 1 280 × 800 pixel resolution.
Multi-touch screen with numeric and alphanumeric onscreen keyboards.
PROFINET, TCP/IP, DHCP, SNMP, DCP, LLDP and MRP support.
2 industrial Ethernet interfaces with 2 switch ports and 1 independent port.
Rated supply voltage: 24 V DC; permissible range: 19.2 V to 28.8 V.
Pedestal mounting in vertical position; landscape format is possible, portrait format is not.
Frequently Asked Questions
What is the exact product model?
The exact product model is Siemens 6AV2128-3MB27-1BX0, product type MTP1200 Unified Comfort PRO.
What display and touch configuration does it have?
It has a 12.1 in widescreen TFT display with 1 280 × 800 pixel resolution, 16 777 216 colors and multi-touch operation.
What interfaces are available?
It has 2 industrial Ethernet interfaces with 2 switch ports and 1 independent port, 1 combined RS 422 / 485 interface, 4 USB 3.1 Gen. 1 type A interfaces and 2 SD card slots.
What mounting configuration does this line item have?
It has pedestal mounting in a vertical position. Landscape mounting is possible, portrait mounting is not, and the maximum permissible angle of inclination without external ventilation is 35°.
Can you include this exact line item in a quotation?
Yes. Provide the requested quantity, destination, schedule context and any additional BOM lines for quotation preparation.
