Product Overview
Technical Summary
| Product type | MTP2200 Unified Comfort PRO |
|---|---|
| Display | 21.5 in widescreen TFT, 1 920 pixel × 1 080 pixel |
| Touch operation | Multi-touch screen with onscreen keyboard |
| Interfaces | 2 industrial Ethernet interfaces; 1 RS 422 / 485 combined interface; 4 USB 3.1 Gen. 1 type A interfaces; 2 SD card slots |
| Protocols | PROFINET, TCP/IP, DHCP, SNMP, DCP, LLDP, and MRP |
| Supply | 24 V DC; permissible range 19.2 V to 28.8 V |
| Mounting | Support arm; vertical; landscape format possible |
| Protection | IP65 at the front and rear |
Key Features
TFT display with 1 920 pixel horizontal resolution, 1 080 pixel vertical resolution, and 16 777 216 colors.
Multi-touch screen with numeric and alphanumeric onscreen keyboard.
2 industrial Ethernet interfaces with 2 switch ports plus 1 independent port; PROFINET, TCP/IP, DHCP, SNMP, DCP, LLDP, and MRP supported.
Rated supply voltage: 24 V DC; permissible range: 19.2 V to 28.8 V.
Support-arm mounting in vertical position; landscape format possible; portrait format is not possible.
IP65 at the front and rear; Enclosure Type 4, Type 4x, and Type 12 at the front.
Frequently Asked Questions
What is the exact product type of 6AV2128-3XB27-0BX0?
The product type designation is MTP2200 Unified Comfort PRO.
What display and touch configuration does it have?
It has a 21.5 in TFT display with 1 920 pixel × 1 080 pixel resolution, 16 777 216 colors, and multi-touch operation.
Which interfaces are available?
It has 2 industrial Ethernet interfaces, 1 RS 422 / 485 combined interface, 4 USB 3.1 Gen. 1 type A interfaces, and 2 SD card slots.
What mounting configuration does it use?
It uses support-arm mounting in a vertical position. Landscape format is possible, while portrait format is not possible.
Is PROFINET IO protocol support included?
It is without support for the PROFINET IO protocol.
