Product Overview
Technical Summary
| Product type | MTP2200 Unified Comfort PRO |
|---|---|
| Display | 21.5 in widescreen TFT, 16 777 216 colors |
| Resolution | 1 920 x 1 080 pixel |
| Mounting | Pedestal; vertical position; maximum permissible angle of inclination without external ventilation: 35° |
| Supply | 24 V DC; permissible range 19.2 V to 28.8 V |
| Industrial Ethernet | 2 interfaces; 2 ports on integrated switch plus 1 independent port |
| Serial interface | 1 combined RS 422 / 485 interface |
| USB interfaces | 4; USB 3.1 Gen. 1 type A |
| SD card slots | 2 |
| Protection | IP65 at the front and rear |
| Configuration | Configurable as of Comfort V18 |
Key Features
21.5 in widescreen TFT display with 16 777 216 colors and 1 920 x 1 080 pixel resolution.
Touch screen and multi-touch screen with numeric and alphanumeric onscreen keyboard.
Pedestal mounting in vertical position; landscape format is possible, portrait format is not.
24 V DC rated supply with a permissible range of 19.2 V to 28.8 V.
2 industrial Ethernet interfaces with 2 ports on an integrated switch plus 1 independent port, 1 combined RS 422 / 485 interface, 4 USB 3.1 Gen. 1 type A interfaces, and 2 SD card slots.
IP65 at the front and rear; configurable as of Comfort V18; contains open-source software provided free of charge.
Frequently Asked Questions
What exact product variant is 6AV2128-3XB27-1BX0?
It is a Siemens SIMATIC HMI MTP2200 PRO with product type designation MTP2200 Unified Comfort PRO.
What display and mounting configuration does it have?
It has a 21.5 in widescreen TFT display with 1 920 x 1 080 pixel resolution. Mounting is pedestal and vertical; landscape format is possible, while portrait format is not.
Which interfaces are included?
It has 2 industrial Ethernet interfaces, 1 combined RS 422 / 485 interface, 4 USB 3.1 Gen. 1 type A interfaces, and 2 SD card slots.
