Product Overview
Technical Summary
| Product type | MTP2200 Unified Comfort Hygienic |
|---|---|
| Display | 21.5 in widescreen TFT, 1 920 pixel x 1 080 pixel, 16 777 216 colors |
| Touch operation | Touch screen and multi-touch screen with onscreen keyboard |
| Supply | 24 V DC; permissible range 19.2 V to 28.8 V |
| Industrial Ethernet | 2 interfaces; 2 ports (switch) + independent port |
| PROFINET | Yes |
| USB interfaces | 4; USB 3.1 Gen. 1 (type A) |
| Protection | IP69 at the front; IP20 at the rear |
| Mounting | Horizontal or vertical; portrait or landscape; maximum permissible angle of inclination without external ventilation: 35° |
| Configuration | Configurable as of WinCC Unified Comfort V17 |
Key Features
21.5 in widescreen TFT display with 1 920 pixel horizontal resolution, 1 080 pixel vertical resolution, and 16 777 216 colors.
Touch screen and multi-touch screen with numeric and alphanumeric onscreen keyboards.
Stainless-steel hygienic design with a blue FDA-compliant gasket and increased impact protection with splinter protection display front according to DIN EN 1672-2 and FDA 21 CFR 177.2006.
DC supply with a rated value of 24 V and a permissible range from 19.2 V to 28.8 V.
2 industrial Ethernet interfaces with 2 ports (switch) plus an independent port, 1 combined RS 422 / 485 interface, 4 USB 3.1 Gen. 1 type A interfaces, and 2 SD card slots.
IP69 at the front and IP20 at the rear; horizontal or vertical mounting, including portrait and landscape formats, with a maximum permissible angle of inclination without external ventilation of 35°.
Frequently Asked Questions
What is the exact product variant?
The exact product is Siemens 6AV2128-3XB40-0AX0, product type MTP2200 Unified Comfort Hygienic.
What supply and network interfaces does it have?
It has a 24 V DC supply, 2 industrial Ethernet interfaces with 2 switch ports plus an independent port, and 1 combined RS 422 / 485 interface.
How can this panel be mounted?
It supports horizontal and vertical mounting, including portrait and landscape formats. The maximum permissible angle of inclination without external ventilation is 35°.
What should be included in a quotation request for this line item?
Provide the requested quantity, destination, schedule context, and any additional BOM lines for quotation review.
